Propulsion System & Tank Capacities
RC CRAFT with SINGLE BEAM ECHO SOUNDER
The purpose built shallow water Survey craft , SC ELENA can be fitted with choice of portable side mounted or towed survey spread.
SC ELENA is ideal for surveying pre/post trenching, pre/post pipe line installation and pre/post dredging from 0.7m to 40m water depth.There are numerus advantageous to utilise
SC ELENA for surveying ports, harbors, channels, banks, beach, rivers and water ways. Coastal areas up to 12Nmiles within territorial waters. Very low fuel consumption and is stable at low speed of 3 to 4 knots.
The craft is road transportable and can be launched from a low-loader for long distance or a tractor for short distance. Easily deployed offshore from a barge or vessel and operational within an hour of arrival on site. Easy excess to shipyards and does not require much storage area onboard. Survey equipment can be deployed both Port & Starboard side. Transit speed up to 10 -12 knots, 2 crew and 12 maximum passengers. Craft is international registered with the required H&M and P&I insurance. SC ELENA can be easily shipped by cargo vessel to anywhere in Asia Pacific and the Middle East. Marine crew have over 5 years’ experience in the survey industry,
She has the required safety documents and compliant with the offshore operations. Aircon cabin and a toilet.
Fuel and engine oil consumption is considered very low (diesel engine). Crew Indonesian English speaking and is experience in survey operation and on running survey lines. This is critical as currents can be very strong in some areas and changes direction frequently.
Engine : Nissan FE-6 Diesel, 180HP (In-board type)
Endurance : 800 liters of Diesel fuel, 80-100 liters per day 12hrs operation.
Principal Dimensions
- Length : 10.9 m
- Beam : 2.5 m
Draft : 0.75 m
Weight : 10 MT
Hull and Superstructure
Material : Fiberglass construction
Non-Slip Deck
Hydraulic Steering Systems
Model : BELL 36
Enclosed work cabin
Air-conditioned
Toilet
Navigation and Communication Equipment
VHF Radio ICOM
GPS
Auxiliary Equipment
3KVM 220v Generator
Bilge/GS: 4 x TMC Submersible Bilge Pump
Fire Fighting – Life Saving
Fire Fighting : 2 x 4.5 kg Foam Fire Extinguisher
Life Saving : Life Jackets and Life Buoys
Certification of Registry
Offical No : SLR10632
Call Sign : 9LU 2645
MPA Harbour craft: SR3826A
Shallow water survey craft
